This series pack granular products such as seasoning, monosodium glutamate, sugar, tea, coffe, pepper, desiccating agents and seeds etc.
| DCK-200 Automatic Granule Packing Machine | ||
| Method of Measurement | Cup Type |  |
| Range of Measurement | 5-100ml Unadjustable cu for 5ml and below | |
| Packing Spee | 40-60(bag/min) | |
| Bag Size | (W): 30-100mm (L): 30-120mm | |
| Sealing Type | Three-side sealing | |
| Total Power | 1215W | |
| Voltage | 380V or 220V 50HZ | |
| Machine Weight | 190kgs | |
| Machine Size | 625*751*1558mm |
| DCK-240/300 Granule Packing Machine (Zigzag cutter) | |||
| Specification Model | DCK-240 | DCK-300 |  |
| Method of Measurement | Cup Type | ||
| Range of Measurement | 5-100ml Single layer measuring Plate divided into six equal parts | 5-330ml 5-80ml single layer Measuring plate divided into six equal parts 50-330ml single layer Measuring plate divided into four equal parts | |
| Unadjustable cup for 5ml and below | |||
| Packing Speed | 40-60(bag/min) | 20-40(bag/min) 30-50(bag/min) 40-60(bag/min) | |
| Bag Size | (W): 30-100mm (L): 30-120mm | (W): 30-150mm (L): 30-170mm | |
| Bag Sizes are customizable | |||
| Sealing Type | Three-side/Four-side sealing | Three-side/Four-side sealing | |
| Total Power | 1400W | 1600W | |
| Voltage | 380V or 220V 50HZ or made accordingly | ||
| Machine Weight | 200kgs | 250kgs | |
| Machine Size | 625*751*1558mm | 930*730*1700mm |
| DCK-240/300 Granule Packing Machine (Pneumatic straight cutter with tear notch) | |||
| Specification Model | DCK-240 | DCK-300 |  |
| Method of Measurement | Cup Type | ||
| Range of Measurement | 5-100ml Single layer measuring Plate divided into six equal parts | 5-330ml 5-80ml single layer Measuring plate divided into six equal parts 50-330ml single layer Measuring plate divided into four equal parts | |
| Unadjustable cup for 5ml and below | |||
| Packing Speed | 40-60(bag/min) | 20-40(bag/min) 30-50(bag/min) 40-60(bag/min) | |
| Bag Size | (W): 30-100mm (L): 30-120mm | (W): 30-150mm (L): 30-170mm | |
| Bag Sizes are customizable | |||
| Sealing Type | Three-side/Four-side sealing | Three-side/Four-side sealing | |
| Total Power | 1400W | 1600W | |
| Voltage | 380V or 220V 50HZ or made accordingly | ||
| Machine Weight | 200kgs | 250kgs | |
| Machine Size | 625*751*1558mm | 930*730*1700mm |
| DCK-300 Automatic Back Sealing Granule Packing Machine | ||
| Method of Measurement | Cup Type |  |
| Range of Measurement | 5-330ml 5-80ml single layer Measuring plate divded into six qual parts 50-330ml single layer Measuring plate divided into four equal parts Unadjustable cup for 5ml and below | |
| Packing Speed | 20-40(bag/min) 30-50(bag/min) 40-60(bag/min) | |
| Bag Size | (W): 10-140mm (L): 30-170mm Bag Sizes are customizable | |
| Sealing Type | Back sealing | |
| Total Power | 1600W | |
| Voltage | 380V or 220V 50HZ or made accordingly | |
| Machine Weight | 250kgs | |
| Machine Size | 930*730*1700mm |
GRANULE PACKAGING MACHINE
Use: granular products such as seasoning, MSG, sugar, tea, coffee, pepper, desiccating agents and seeds etc.
Model: DCK240/300
Speed: 40-60 bags/min
1、Product Description:
The granule packaging machine pack granular products such as seasoning, MSG, sugar, tea, coffee, pepper, desiccating agents and seeds etc.
Automatic Three-side Granule Packing Machine
1. Can finish the function of bag making, measuring,filling,sealing,cutting and counting.
2. Controlled by computer and step motor pull bag, flexible bag length cutting, operator needn’t to adjust the unloading working, saving time and saving films.
3. Separate PID control to temperature, suitable for various packing materials.
4. Option device: ribbon printer, filling device, gas-exhaust device, horizontal sealing punching device, rotary cutter, small cutter, former beat device, batch pneumatic cutter.
5. Simple driven system, working more stable and easy to maintain.
6. Packing material:(PET/PE), (Paper/PE), (PET/AL/PE), (OPP/PE)
2、Advantages:
– Automatic packing machine
– Each to adjust bag length
– Simple driving system
– Easy cleaning
– Touch material:ss304
3、Technical Parameters:
PLC screen, intelligent control, failure warning, Solid intelligence double road temperature control, The design of circulatory wind-electric cabinet for 24 hours working, 304 stainless steel.
Specification
| Model | DCK-240 | DCK-300 |
| Bag type | 3 /4 side sealing | 3 /4 side sealing, back sealing Triangle sealing |
| Method of Measurement | Cup type | |
| Range of Measurement | 5-100ml | 5-330ml |
| Packing Speed | 40-60bag/min | |
| Bag Size | W: 30-120mm L:30-170mm | W: 30-150mm L:30-170mm |
| Total Power | 1400W | 1600W |
| Voltage | 380V or 220V or made accordingly | 380V or 220V or made accordingly |
| Machine weight | 200kg | 250kg |
| Machine Size | 625*751*1558mm | 930*730*1700mm |
4、Kindly Reminder:
Please let us know the follow packing details when you offer,so that we can check if this model is suitable for your case.Thank you in advance.
1. Product details (description/photos/samples are all ok)
2. Bag width & bag length
3. Bag shape
4. Packing film material
5. Machine frame material (SS frame or carbon steel frame)
